Sawdust making machine wood crusher hammer mill

  • Product Name: Wood Hammer Mill
  • Model: YGFS65*75/100
  • Power: 55kw
  • Capacity: 1-10t/h
  • Finished Size: 5-6mm
  • INQUIRY

The wood hammer mill will be passed by the dynamic balance testing, the error of hammers is within 0.2g, which can guarantee the machine runs stablely.

The materials of hammers is tungsten carbide spot welding. The hammers of hammer mill is thick; the effect is better.

Siemens Motor. It is frequency and has thick copper coil, it won’t be burned due to instantaneous current.

Feed inlet of hammer mill with anti-caulking baffle to prevent material collapse

Parameter

Model

Power

(kw)

Output

(t/h)

Hammer Qty

(pcs)

YDFC50150.6-0.816
YDFC65*27
220.5-0.824
YGFS65*5537/451-272
YGFS65*7555/751.5-2.5108
YGFS65*10090/1103-4144
YSFS65*7555/75*24-5216
YSFS65*100920/110925-6218


Raw Material

High efficiency wood sawdust producing wood crusher machine hammer mill(图1)High efficiency wood sawdust producing wood crusher machine hammer mill(图2)High efficiency wood sawdust producing wood crusher machine hammer mill(图3)High efficiency wood sawdust producing wood crusher machine hammer mill(图4)High efficiency wood sawdust producing wood crusher machine hammer mill(图5)
      Wood Chips              Straw    Wood Branches   Wood Shavings            Shell


1.Motor of hammer mill use Siemens Brand. This kind of motor is frequency and has thick copper coil, it won’t be burned due to instantaneous current.

2.The rotor of wood crusher will be passed by the dynamic balance testing, the error of hammers is within 0.2g, which can guarantee the machine runs stablely.

High efficiency wood sawdust producing wood crusher machine hammer mill(图6)

High efficiency wood sawdust producing wood crusher machine hammer mill(图7)


3.Bearing block of hammer mill for sale is made of bearing steel. The bearing block is big and wide, which makes sure that the hammer mill run steadily.

4.The materials of hammers is tungsten carbide spot welding. The hammers of hammer mill is thick; the effect is better.

High efficiency wood sawdust producing wood crusher machine hammer mill(图8)High efficiency wood sawdust producing wood crusher machine hammer mill(图9)


5.The discharge port of sawdust making machine is high and the material is not blocked

6. Feed inlet of crushing machinery with anti-caulking baffle to prevent material collapse

7.Hammer mill feeding materials vertically, feeding smoothly.

High efficiency wood sawdust producing wood crusher machine hammer mill(图10)High efficiency wood sawdust producing wood crusher machine hammer mill(图11)
